Picotig · 2085PTG0006
EWM Picotig 220 puls DC 5P - TIG DC inverter welder, portable, gas-cooled, 5 pole, with PFC module. Technical data see details.
Fig. may deviate

Description

Picotig 220 puls DC 5P

- TIG DC inverter welder, portable, gas-cooled, 5 pole, with PFC module
- Multivolt/multivoltage capable: Can be used worldwide without any problems thanks to
automatic adjustment of the mains voltage (110 - 120 V / 230 V)
- Comfort 3.0 mini control unit with two easy-to-read 7-segment displays for the
quick and easy selection of the most important parameters
- 5-pin digital welding torch connection with X technology enables the
connection of Retox XQ Torch holders
- Highly efficient power consumption thanks to integrated PFC technology (Power Factor
correction technology)

Process and functions
▪ TIG-DC and TIG pulse
▪ 2-cycle/4-cycle operation
▪ spotmatic and spotArc
▪ E-hand, E-hand pulse, E-hand cel, E-hand cel pulse
▪ Find out more about our high-tech
tIG arcs
▪ Adjustable hot start current and hot start time
▪ Adjustable arcforce
antistick function

Your advantages
▪ Connection option for remote control and function burner
▪ Unrestricted generator operation even with long mains supply cables thanks to high mains voltage tolerances
▪ Power-saving thanks to high efficiency and standby function
▪ Robust housing with impact-resistant plastic cover
▪ Temperature and speed-controlled cooling fan - less soiling and lower noise emissions
as the fan only runs when required
splash-proof in accordance with IP23
▪ Wear parts box in the handle - burner wear parts always safely stored and ready to hand
▪ With cable holder as standard to hold the mains cable
▪ The standard protective flap protects the control unit from water, dirt or impacts
▪ 3.5 m mains cable with 16 A Schuko plug
▪ Overvoltage protection: No damage to the device due to accidental connection to 400 V mains voltage

Technical specifications
Model Picotig 220 puls DC 5P
Welding current setting range 5 A - 220 A
Welding current setting range 110 V - 120 V 5 A - 170 A
Duty cycle 40 °C 220 A / 40 %
190 A / 60 %
160 A / 100 %
Duty cycle 110 V - 120 V 170 A / 40 %
150 A / 60 %
120 A / 100 %
Open circuit voltage 97 V
Mains voltage (ex works) 1 x 230 V
Mains voltage (possible) 1 x 110 V - 120 V
Mains tolerances (ex works) -40 % to +15 %
Mains tolerances (ex works) 110 V - 120 V -15 % to +15 %
Mains frequency 50 Hz / 60 Hz
Recommended generator output 6.6 kVA
Recommended generator output 110 V - 120 V 4.6 kVA
Efficiency 84 %
Power consumption Pi 10 W
Protection class IP23
EMC class A
Dimensions (L x W x H) 454 mm x 165 mm x 321 mm
Weight 10 kg
Standards IEC 60974-1, -3, -10 CL.A
