EWM - Tetrix XQ 300 puls AC/DC Expert 3.0 5P (including all characteristics and functions) - TIG AC/DC pulse welding machine
15% Discount = € 1,153.43 Savings
(Prices incl. 19.0% VAT)
Tetrix XQ 300 puls AC/DC Expert 3.0 5P
- Modular TIG AC/DC inverter welding machine of the latest generation
Process and functions
▪ TIG AC/DC, TIG DC and TIG pulse
▪ activArc and spotArc
▪ E-hand, E-hand pulse, E-hand cel, E-hand cel pulse
▪ Find out more about our high-tech TIG arcs
Your advantages
▪ LED status bar indicates the current operating status in colour
▪ Prepared ex works for water cooler connection - guarantees maximum
flexibility in industry and trade
▪ No additional mains connection of the cooling module necessary. The power supply
of the module is via the welding machine
▪ Robust housing with impact-resistant plastic cover
▪ Temperature and speed-controlled cooling fan - reduced soiling and
less noise emission as the fan only runs when required
splash-proof in accordance with IP23
▪ Suitable for generators even with long mains cables
▪ High mains voltage tolerances
▪ Wear parts box in the handle - burner wear parts always safely stored
and ready to hand
▪ Can be optionally networked via LAN or WiFi gateway with ewm Xnet software
▪ 5.5 m mains cable
| Technical data | |||
|---|---|---|---|
| Version | Tetrix XQ 300 puls AC/DC Expert 3.0 5P | ||
| Welding current setting range | 3 A - 300 A | ||
| Duty cycle 40 °C | 300 A / 40 % | ||
| 270 A / 60 % | |||
| 220 A / 100 % | |||
| Open-circuit voltage | 87 V | ||
| Mains voltage (ex works) | 3 x 380 V - 400 V | ||
| Mains tolerances (ex works) | -25 % to +20 % | ||
| Mains frequency | 50 Hz / 60 Hz | ||
| recomm. Generator output | 15.9 kVA | ||
| Efficiency | 83 % | ||
| Power consumption Pi | 24 W | ||
| Protection class | IP23 | ||
| EMC class | A | ||
| Dimensions (L x W x H) | 550 mm x 257 mm x 415 mm | ||
| Weight | 22 kg | ||
| Standards | IEC 60974-1, -3, -10 CL.A | ||
