EWM - TIG 260 WD GRIP 5P RETOX XQ HFL 8 m, water-cooled Torch holder with highly flexible hosepack (High-Flex leather)
Fig. may deviate
Description
EWM TIG 260 WD GRIP 5P RETOX XQ HFL 8 m, Water-cooled TIG torch holder with highly flexible hosepack (high-flex leather), Ergonomic GRIP handle for a secure grip.
TIG 260 WD GRIP 5P RETOX XQ HFL 8 m
- Water-cooled TIG torch holder with highly flexible
hosepack (High-Flex-Leather)
- Adjustment and display of welding current and programmes
- Ergonomic GRIP handle for a secure grip
and ergonomics
- Retox Torch holder exclusively for operation on
tetrix XQ puls
- Excellent HF safety
- Equipment ex works:
- Electrode holder: Ø 2.4 mm
- Gas nozzle: Ø 9.5 mm, size 8
- Tungsten electrode E3 (purple): Ø 2.4 mm
- Torch cap "medium"
Technical Data
| Configuration | High-flex leather |
| Duty cycle | DC- 260 A / 100 % |
| Duty cycle | AC 185 A / 100 % |
| Connection poles | Tuchel, 5-pole |
| Burner connection | Decentralised 35 mm² (Ø arbor 13 mm) |
| Control cable connection | Tuchel, 5-pole |
| Protective gas line | G 1/4" RH, union nut |
| Hose package length | 8 m |
