Fortis · 2143FOR0002

MIG/MAG welding with the Fortis

The integrated device design of the Fortis is based on a compact system with a maximum output current of up to 500 A.

Space for the optional cooling circuit is also provided in the overall housing. This enables
space-saving installation and utilisation, even in environments with limited space.

In addition to the compact version, models with an external wire feeder are also available for an extended operating range.
The Pulse function can also be used with an intermediate hosepack length of up to 15 metres.

The all-in-one system: one device, many possibilities

- Compact welding devices up to 500 A
- Retrofitting of water cooling at 320, 400, 500 A possible at any time
- Split versions with external feed for an extended operating range
- Duo variant: Compact welding units from 320 A can be combined with an additional wire feeder
- One user interface for all variants

Equipped for all applications
The Fortis series focuses on reliable and stable welding performance for manual applications.
The outstanding ignition properties and stable arc allow a wide range of applications to be covered.
can be covered.

All important welding parameters at a glance
With our digital, clear user interface, you always have the most important welding parameters at a glance.
at a glance. Fast process changes, more than 30 adjustable system languages and customisable
Customisable parameter settings are just a few of the highlights that ensure particularly simple and intuitive handling.
handling.

One device - all welding processes
Whether MIG/MAG, TIG or MMA welding, our Fortis welding machines with multi-process function offer
maximum flexibility for almost all areas of application.

Welding connects
The Fortis series is compatible with our innovative WeldCube Air and WeldCube Premium software solutions.
The Vizor Connect welding helmet and Bluetooth remote controls also offer you additional expansion options.

High recycling rate, few application errors
The recycled aluminium content of the Fortis series is 53% in order to minimise the ecological footprint
as possible. The intuitive operation of the devices, in particular the welding parameter wizard, minimises
Minimise application errors. The housing concept and good serviceability contribute to a long service life of the devices.

XT variant: Fortis 270-500

A real all-rounder: XT stands for Extended, as the Fortis Extended version is designed for the following applications
for mains voltages from 200 to 600 V and can therefore be used worldwide. Depending on the power class
and the mains fuse protection, up to 320 A are possible in single-phase operation.

Special features of the XT variant

- Available in all power classes (270-500 A)
- Can be used worldwide
- Single-phase operation up to max. 320 A (depending on existing mains fuse protection)
- Fully suitable for generators
- Optimised welding performance due to higher output characteristic curve
- Energy savings of up to 16 % compared to the standard version
- CEL-compatible
