THP 180 / TTB 160 · 1850THP0157
Fronius TTB 160P G ML /70°/L50 (Bolted) - Multilock torch body (without hosepack)
Fig. may deviate

Description

Fronius TTB 160P G ML /70°/L50 (Bolted)

Multilock burner body
Simply flexible welding: The Multilock system offers a selection of different torch bodies
Torch bodies in various lengths and angles. Thanks to the ergonomically shaped handle shell
and optimised weight distribution also significantly reduce physical strain.
For maximum flexibility in every welding application and fatigue-free working!

Standard equipment:

- Interchangeable torch body only with CU 600t Pro (with torch deflate function) and for servicing
- Minimised gas consumption thanks to gas non-return valve
- Endlessly rotatable burner body
- Plugged gas nozzle for burner body A
- Screwed gas nozzle for burner body P
- Non-slip handle with soft components
- Interchangeable user interface
- LED lighting
- Ball joint on grip shell side
- 0.8 m leather protection hose
- Proven F++ central connection with TMC control cable plug

Technical data
TTB 160P
Dimension / width 50 mm
Dimension / height 23 mm
Dimension / length 110 mm
Electrode diameter range 1.0 - 3.2 mm
Weight 0.14 kg
Cooling system (gas-cooled, water-cooled) G
Welding current / duty cycle [AC] 49A / 100%
Welding current / duty cycle [AC] 63A / 60%
Welding current / duty cycle [DC] 63A / 100%
Welding current / duty cycle [DC] 84A / 60%
