Fronius - TTB 220A G F ML/70°/L65 (plugged) - Multilock torch body flexible (without hose assembly)
Fronius TTB 220A G F ML/70°/L65 (Plugged)
The new TIG welding torches can be adapted individually - matched to the personal
preferences of the welder as well as to the respective welding application.
For even more possibilities to adapt the torch to the welding task, from flexible
torch bodies available immediately. The flexible torch bodies can be used with
difficult accesses can be bent to the desired position. As well as with the rigid
torch bodies, the flexible torch body is endlessly rotatable.
The Up/Down torch has the following
functions:
Change the welding power using the up/
down key (+/-)
LED for illuminating the welding point:
- Press key once:
LED lights up for 5 s
- Hold down key:
LED lights up constantly
Cap-shaping in connection with the TIG
AC welding process
Intermediate lowering in connection with
4-stroke operating mode (I1 > I2)
| Technical data | |
|---|---|
| TTB 220 | |
| Welding current at 10 min / 40°C (104°F) DC |
35 % ED* 220 60 % ED* 170 100 % ED* 130 |
| Welding current at 10 min / 40°C (104°F) AC |
35 % ED* 180 60 % ED* 130 100 % ED* 100 |
| Standard | EN 439 |
| Dimension mm in. |
1,0 - 4,0 0.039 - 0.158 |
* D.C. = duty cycle
