Procedure
TIG-DC
TIG-AC/DC

Recommended base materials
CrNi steels ferritic / austenitic
Duplex steels
Nickel-based materials
Aluminium materials
Magnesium materials
Copper materials

Recommended areas of application
Plant, container, machine and steel construction
Automotive and supplier industry
Special machine construction / construction machinery
Chemical plant engineering
Maintenance / Repair
Pipeline construction
Rail vehicle construction
Shipbuilding / Offshore

Options
TIG robot welding torch:
Customised hose package lengths 1.0
- 20 m (from 12 m HF ignition may be impaired)
Extension for retaining clamp
Initial equipment set for TIG RO KD-Drive
Wire feed speed 0 - 5 m/min or 0 - 22 m/min
Ignition aid
Gas lens for 3/4" gas nozzle
Customised burner body curvature
90°, 70° for TTW4500 PAP

Standard equipment
Burner head:
Screwable gas nozzle system
Gas lens
Adjustment device for electrode
Hose assembly:
UV and ozone resistant shaft protection hose
Retaining clip (4 x 90° mountable)
Cable for switch-off box
Cold wire feed push:
Wire guide tube swivelling with locking device
Combination core 0.8 - 1.2
Cold wire feed Pull:
Wire feed speed 0 - 10 m/min
Graphite core ø 2.5 mm for Al and CrNi wire
Wire guide tube swivelling with locking device
Exact speed control by digital encoder
Toothed pressure and drive rollers
Drive forward and back button
