A 16 All-rounder for the construction site

Application

• Particularly suitable for thicker sheets from approx. 2 mm
• Automatic compensation of length tolerances of the bolts through integrated length compensation

Construction

• Robust housing made of impact-resistant plastic
• Plain bearing for guiding the welding piston
• Sealed welding piston guide
• Lift adjustment
• Stud length freely adjustable

Safety

• Locking lift setting
• High safety against unintentional change of selected settings
• Guide protected from weld spatter

Welding

• Welding on painted sheets possible (bare weld and ground required)
• Especially suitable for high cycle sequences with large diameters
• Automatic length compensation
• Damped immersion in the weld pool due to built-in oil damper

Welding range	Ø 3 - 16 mm / Ø #4 - 5/8"
Stud length	10 - 240 mm / 0.39" - 9.45" (depending on stand)
Stud type	Any type or shape (special stud holders if required)
Length compensation	6 mm / 0.24" automatic
Lift	Adjustment range 4 mm / 0.16", (0.25 mm / 0.01" steps, latching)
Spring force	Oil damper
Welding cable	4.8 m / 15.75'; 50 mm² / 1/0, SK 50
Protection class	IP 20
Noise level	Up to 90 dB (A) possible for a short time during the welding process
Dimensions in LxWxH (without cable, with base plate)	260 x 74 x 220 mm / 10.24" x 2.91" x 8.66"
Weight (without cable)	2 kg / 4.41 lbs
