C 06-3 with positioning tube PPR-2

Version for welding with templates and to protect against weld spatter,
Easy handling, no adjustment of lift and spring force, aluminium up to M4

Welding application

• Particularly suitable for thin sheets from 0.5 mm
• ISO - Particularly suitable for welding on ISO nails with flange and ignition tip

Construction

• Robust housing made from impact-resistant plastic
• Torsion-resistant base shell (housing) to accommodate all functional elements and accessories (e.g. foot ring)
• Slide bearing for guiding the welding piston
• Sealed welding piston guide
• Ergonomic design
• Compact dimensions
• Stud length freely adjustable (up to 40 mm; from 40 mm with stand)
• Production-proven mechanics

Safety

• High level of safety against unintentional changes to the selected settings
• Guide protected against welding spatter

Welding

• Optimum handling and fatigue-free working
• Optimum working even in hard-to-reach places
• Welding possible on painted sheet metal (bare weld and earth required)

Welding range	M3 - M6, Ø 2 - 6 mm / #4 - 1/4", Ø 14 ga - 1/4"
Stud length	6 - 40 mm / 0.24" - 1.57"; longer studs (> 40 mm / 1.57") with optional accessories
Stud type	Any type or shape (special stud holders if required)
Welding cable	3 m / 9.84'; 25 mm², SK 50
IP code	IP 20
Workplace noise level	> 90 dB (A) possible for short periods during the welding process
Dimensions in LxWxH (without cable)	170 x 40 x 140 mm / 6.70" x 1.57" x 5.51"
Weight (without cable)	0.5 kg / 1.10 lbs
