HBS - CI 03 for welding of plate pins (WKSB - insulation mat fastening), see details.
Description
CI 03
For welding disc pins (WKSB - insulating mat fastening)
Application
- Especially suitable for welding of plate pins (for fastening of heat, cold, sound and fire protection mats - WKSB)
Construction
- Robust housing made of impact-resistant plastic
- Backlash-free ball linear bearing for guiding the welding piston
- Sealed welding piston guide
Safety
- Locking spring adjustment
- High safety against unintentional change of the selected settings
Welding
- No damage on the back side of thin galvanised sheets if specified welding parameters are adhered to; especially for disc pins with Ø 2 mm (zinc, corrosion protection on the back side is maintained)
- Guide protected from weld spatter
Welding range | Plate pins Ø 2/2.7 mm / 14 ga/12 ga |
Stud length | 9.5 - 152.4 mm / 0.37" - 6.00" |
Stud type | Cup pins |
Spring pressure | Adjustable, latching |
Welding cable | 9.3 m / 30.51'; 6 mm², SK 50 |
IP code | IP 20 |
Workplace noise level | > 90 dB (A) possible for short periods during welding process |
Dimensions in LxWxH (without cable) | 175 x 50 x 145 mm / 6.89" x 1.97" x 5.71" (without stand) |
Weight (without cable) | 0.7 kg / 1.54 lbs |
