Laservision Face Shield FS1P1P22 - Scratch-resistant outside / anti-fog inside, light weight, M protection levels, protection range: infrared, near infrared, visible, ultraviolet. The safe and comfortable complete solution for eyes and face.
Fig. may deviate
Description
Laser safety visor FS1P1P22
The safe and comfortable complete solution for eyes and face during hand-held laser welding. The Face Shield (FS1) offers certified laser protection in accordance with EN 207.
The Face Shield sets new standards in terms of wearing comfort. The total weight is only 386 g. Thanks to its ingenious folding mechanism, the system is
spring-loaded coupling rods. The height and width-adjustable headrest with uvex spiderneck neck support rounds off the ergonomic relief
perfectly.
| Coating: | Scratch-resistant on the outside / anti-fog on the inside |
|---|---|
| Features: | Low weight, M protection levels |
| Colour vision: | Excellent |
| Frame: | FS1 |
| Filter: | P1P22 |
| Filter thickness: | approx. 2mm |
| Filter colour: | Blue-grey |
| Filter material: | Plastic |
| Filter technology: | Absorption filter |
| Standards: | EN 166, EN 169, EN 207 full protection, EN 208 adjustment protection |
| Protection range: | Infrared, near infrared, visible, ultraviolet |
| VLT (approx.): | 12% |
| Visual brightness: | Sufficient |
| WAVELENGTH (NM) | OD | OPERATING MODE / TESTED PROTECTION LEVEL |
|---|---|---|
| 180 - 315 | (OD10+) | D LB10 + IR LB4 |
| >315 - 385 | (OD8+) | D LB6 + IRM LB8 |
| >385 - 400 | (OD4+) | DIRM LB4 |
| 660 - <740 | (OD1+) | DIRM LB1 |
| 880 - <946 | (OD5+) | DIRM LB5 |
| 946 - <1030 | (OD6+) | DIRM LB6 |
| 1030 - 1400 | (OD7+) | D LB6 + IRM LB7 |
| >5250 - 14000 | (OD5+) | DI LB3 + R LB3Y |
