CenTIG 200 DC Water
The new CenTIG 200
A new single-phase TIG welder that offers unrivalled performance at 200 amps.
Experience the fusion of power and mobility with exceptionally lightweight equipment,
designed for professional TIG welders.
The most powerful single-phase TIG welder at 200 amps
CenTIG is so robust and reliable that it can be used continuously with its maximum load of 100 %
Duty cycle without any downtime to prevent overheating or overloading
Wear and tear.
The most versatile single-phase TIG welding machine for production
CenTIG can be used for a wide range of applications - from repair work to
to daily production. Configurations include DC and AC/DC models with pulse, air-operated
or water-cooled and with all the necessary functions.
Unlimited welding
With a duty cycle of 100 % at 200 A, a welder can weld without interruption and without
Downtime for as long as necessary on sheets up to 10 mm.
Incredibly compact - even with water cooling
The welder can use his water-cooled CenTIG anywhere in the workshop. The new
compact design takes up very little space.
| technical data | tIG / MMA | cenTIG 200 DC HP / AC/DC |
| current range (TIG) | 5-200 A / 10-137 A | |
| mains voltage +/-15% | 1x230 V | |
| efficiency | 87 % | |
| no-load power | max. 30 W | |
| frequency (AC) | 25-300 Hz | |
| duty cycle 40%/40° | 200 A | |
| duty cycle 60%/40° | 200 A | |
| duty cycle 100%/40° | 200 A | |
| electrode dimension | 1.0-3.2 mm | |
| display size | 7" | |
| mains plug | schuko | |
| front plug | 1 x plug (+) 1 x plug (-) | 1 x burner plug, 7-pin 1 x quick coupling for shielding gas |
| plug on the rear | 1 x CAN connection for water cooling unit | 1 x USB A connector for software update 1 x gas connection 1 x power button |
| dimensions (HxWxL) | 356 x 210 x 543 mm | |
| weight (AC/DC) | 12.7 kg | |
| weight (DC) | 12 kg | |
| application class | s/CE | |
| protection class | iP 23S | |
| operating temperature range | -10 - +40 °C | |
| standards | dS/EN IEC 60974-1 dS/EN IEC 60974-10, class A dS/EN IEC 60974-3 |
