Easy-to-understand user interface with 4.5-inch LCD display
Ensures correct machine set-up and parameter selection.
Informative on-screen explanations and dynamic images improve the parameter selection process.

Programme memory
Enables easy naming, saving and recalling of favourite welding settings.
Increases productivity as parameters no longer need to be set manually.
Provides consistent quality for welders of all qualifications.

Pro-Set
Eliminates the guesswork when setting welding parameters.

Locks and limits.
Enables control of welding parameter ranges and minimises deviation from the welding procedure specification
Specification (WPS).

Auto-Line
Enables connection to any input voltage (120-480 V) without manual linking and provides
Convenience in any working environment. Ideal solution for dirty or unreliable power.

Blue flash
Enables more consistent high frequency (HF) arc starts and higher reliability compared to
conventional arc starters.

USB
The USB port on the front panel can be used to perform software updates, back up settings and save data
transfer saved welding programmes from one device to the next. Visit MillerWelds.com
/TIGSoftware for the latest software updates and enhancements.

Cooler Power Supply (CPS)
Is an integrated 120 volt power outlet for the Coolmate 1.3.

Demand-controlled cooling
The function only switches on the auxiliary cooling system when required, thereby minimising noise, energy consumption and
Contaminants in the air drawn through the cooler.

AC TIG features
The balance control enables adjustable oxide removal, which is ideal for the production of
Aluminium welds of the highest quality.
The frequency controls the width of the arc cone and can control the direction of the arc
improve the directional control of the arc. Improve arc control.

AC waveforms
▪ Advanced Square ensures fast arc freezing, deep penetration and high travel speeds.
▪ Soft Square for a soft, buttery arc with maximum puddle control and good wetting effect.
▪ Sinus for customers who want a traditional arc. Quiet with good wetting.
triangular reduces heat input and is well suited for thin aluminium. Fast travelling speeds.

Independent amplitude/current control allows independent adjustment of EP and EN current levels
can be set independently to precisely control the heat input to the workpiece and the MMA.

AC/DC stick features
DIG control allows arc characteristics to be changed for specific applications and MMA.
Lower the DIG setting for smooth-running MMAs such as E7018 and increase the DIG setting for
stiffer, more penetrating MMAs such as E6010.

▪ The adaptive hot-start control ensures positive arc starts without sticking.
▪ A C frequency control provides additional stability when stick welding with alternating current for smoother weld seams.
▪ Stick-Stuck detects when the electrode sticks to the part and switches off the welding power to safely and easily remove the MMA
to remove the MMA safely and easily. Menu selectable.

DC TIG Features
Exceptionally smooth and precise arc for welding exotic materials.

Pulse waveforms
▪ Rectangular provides a fast freezing weld pool for ultimate arc control.
▪ Sine produces less audible noise and provides a more fluid weld pool that is well suited for overlaps.
applications suitable for.
triangular provides a fast-forming weld pool while reducing heat for thin materials.
