Miller - Miller MigMatic 260i MIG/MAG (incl. earth cable and wire feed rolls 1.0-1.2 mm), gas / water, steel, 0.8-1.2 mm
Switch for trigger programme
Call up to 4 preset programmes via the burner switch
(any standard MIG torch) for increased productivity on complex objects.
Miller robustness
Tested and approved for high-performance welding under the toughest conditions.
Miller goes to extreme lengths to ensure trouble-free welding in every environment
Environment.
Heavy duty wire drive mechanism
The 4-roller drive system ensures trouble-free wire feed.
Energy efficient
The energy-saving fan-on-demand power source cooling system only operates when required.
This reduces noise levels and the amount of contamination caused by
drawn through the machine.
Fully synergic MIG/MAG with presets
Synergic lines for all common wire/gas combinations with preset
Start/stop parameters for optimum weld seams.
Ease of use and versatility
Large, intuitive LCD display for quick and precise setting of the welding parameters
advanced welding parameters.
|
Technical data |
|||
|---|---|---|---|
| MigMatic 260i | MIG/MAG | ||
| Industries of interest | General manufacturing Car repair Training centres Agricultural equipment Repair and maintenance |
||
| Weldable metals | From thin to thick, All materials, 0.8-1.2 mm solid, Cored wires |
||
| Input voltage | 400 V | ||
| Input phase | 3 phases | ||
| Input Hz | 50/60 Hz | ||
| Current range | 15 A - 260 A | ||
| Max. Output current | 285 A | ||
| Rated power | 260 A, 27 V at 35 % duty cycle | ||
| Maximum open-circuit voltage | 70 VDC | ||
| Width | 470 mm | ||
| Height | 830 mm | ||
| Length | 1070 mm | ||
| Weight | 57 kg | ||
