1.4316 · 352WTS0001
1.4316 / 19 9LSi / 308LSI / 1.0 mm stainless steel TIG/TIG rods 1.0 x 1000 mm with flat embossing, price per box incl. alloy surcharge, please enquire about approvals and scope of approval if required, PU = 5 kg.
Fig. may deviate

Description

Area of application:
Joint welding of stainless and heat-resistant steels.
Corrosion-resistant build-up welding.

Base materials:
1.4301 1.4306 1.4550 1.4319
1.4541 1.4311 1.4551 1.4552
TÜV data sheet 1000: Group 29

Standard designation:
DIN 8556: SG x 2 CrNi 19 9
EN 12072: G/W 19 9 L Si
Material no. 1.4316
AWS designation: ER 308LSi

Mechanical properties of the weld metal (standard values):
Yield strength (Re) 390 N/mm2
Tensile strength (Rm) 590 N/mm2
Elongation (A)(Lo=5do) 35%
Notched impact energy (Av) 70 J
Highest operating temp. 350°C
Lowest operating temp. -196°C
