Paton - MMA MINI welding machine 150A, Includes: 3m welding cable with electrode holder, 2m cable with earth clamp, PATON plastic case, Dimensions (W x L x H mm): 200 х 100 х 235 Affordable quality product! see details
MINI Stick Welder Inverter Paton 150A
The MINI Stick Welder Paton welding machine is designed for manual MMA arc welding with direct current.
The MINI series is intended for users who require a functional device with the full rated current of 150A.
This is sufficient to work with any MMA from 1.6 mm up to and including 4 mm, with a duty cycle of
of at least 40 %, which is sufficient to carry out most tasks in the domestic sector (cottages, small workshops, etc.),
Car repair shops, etc.).
The modern digital display allows you to set the exact welding current you want to work with.
Thanks to its solid and compact design, the MINI series welding machine is perfect for working in front of
On-site and for domestic use. The small size of the device makes it very mobile. The PATON MINI welding machine is
equipped with a work stabilisation system so that it can be operated with a generator.
The main advantages of the PATON MINI stick welder:
- European production of welding machines
- Infinitely adjustable welding current
- Possibility to work with long extension cables and a generator
- All electronic components are impregnated with two layers of high-quality paint,
which ensures the reliability of the product throughout its service life
- Improved arc glow stability
- Hot-start, arc-force and anti-force functions
- Protection against voltage peaks and stabilisation system to ensure
proper operation in the voltage range from 170 V to 260 V
- Twice the power consumption compared to conventional sources
Highest manufacturing quality, confirmed by a 3-year DOOR-to-DOOR manufacturer's warranty.
With the MINI model, the frequency of the input voltage that feeds the transformer is reduced by one
Transformer is many times lower, so that the device is much more efficient with the same output parameters compared to other
Other devices with similar characteristics.
MINI welding unit set consisting of:
▪ MMA Paton MINI 150A welding machine
▪ Electrode holder 3m
▪ Earth cable 2m
▪ Professional transport case
▪ Carrying strap
▪ User manual
Technical data
| Nominal supply voltage 50/60 Hz | 230 V |
| Required rated mains current | 18,5 A |
| Nominal welding current | 150 A |
| Maximum welding current | 180 A |
| Work cycle | 40% - 150 А 100% - 94 А |
| Intervals for changing the supply voltage | 170 - 260 V |
| Welding current setting intervals | 20 - 150 A |
| Hot start function | Automatic |
| Arc-Force function | Automatic |
| Anti-stick function | Automatic |
| Open circuit voltage MMA | 70 V |
| Voltage of the electric arc ignition current | 110 V |
| Rated power consumption | 4.0 kVA |
| Maximum power consumption | 5.0 kVA |
| Energy efficiency | 90% |
| Cooling | |
| Operating temperature range | -25 ... +45 ºC |
| Complies with the standards: | EN 60204 - 1:2006 EN 60974 - 1:2012 EN 60974 - 10:2014 |
| Dimensions, mm (length, width, height, width) | 200 х 100 х 200 |
| Weight | 3.3 kg |
| Protection class | IP 21 |
