PRO-40 Practical core drill

PRO-40 with dedicated motor and 1-speed gearbox 440 rpm is optimised to achieve a
appropriate speed for working with HSS cutters up to 40 mm and twist drills
up to 16 mm. The rigid design, optimised by FEA software
(finite element analysis), extends the service life of the tool and enables a longer tool life
Cutting depth of up to 75 mm.

Functions and advantages

The compact design and the innovative, intelligent magnet with reduced weight make the machine
a lightweight. The PRO-40 offers maximum holding force thanks to magnetic field shape control (MFSC)
on thin materials. The drill and the operator are protected by the magnetic force adhesion control module
(MPAC) protects the drill and operator from working on workpieces that are too thin. PRO-40 is also equipped with a
Energy Saving Base (ESB), which consumes only 50% of its power when the motor is not running.

Scope of delivery:

/ Drill
/ System case / Operating instructions
/ Coolant - Lubricant container
/ Assembly tool (3x Allen key, 1x 8 mm spanner, 2x centring pin)
/ chain
/ drill bit:

1x drill 12x50
1x drill bit 14x40
1x drill 16x50
1x drill bit 18x50
1x drill bit 20x50
1x drill 22x50
1x drill 25x50
1x drill bit 30x50
1x drill 40x50
