PRO-36 MS - Drilling machine for special applications
The machine with swivelling magnetic feet is designed for operation with convex (min. diameter 300 mm) and concave (min. diameter 300 mm) drilling tools
(min. diameter 1000 mm) materials. The magnetic feet are equipped with very strong neodymium magnets
and requires no electricity for operation. Four individual swivel magnets adapt to the surface so that
the machine does not require perfectly flat material. In addition, each magnet is equipped with a variable holding force
equipped. This allows easy positioning of the machine while the magnets are partially engaged
are partially engaged. The magnetic base does not require any electricity, thus providing more safety in case of power failure.
Features and benefits:
The most compact unit developed by Promotech and one of the smallest units in the world.
PRO-36's outstanding features include:
▪ ultra-light weight
▪ Gearbox and pusher system as one unit
▪ Purpose-designed motor with heavy-duty gearbox
▪ Maintenance-friendly design
▪ maintenance-free rail guide system
PRO-36 is equipped with a magnetic field shape control (MFSC) and a magnetic force adhesion control (MPAC) module
equipped. These units detect the adhesion force of the electromagnetic base and protect both the
Operator and the machine from working on workpieces that are too thin.
| Technical datapRO-36 MS | |
|---|---|
| Motor speed (under load) | 350 rpm |
| Power | 1020 W |
| Weight | 14 kg |
| Max. Milling capacity | 36 mm |
| Max. Countersinking | 40 mm |
| Stroke | 70 mm |
| Max. Cutting depth | 35 mm |
| Voltage | 1~ 110-120 V, 50-60 Hz 1~ 220-240 V, 50-60 Hz |
| MFSC (magnetic field shape control) | - |
| Magnetic clamping force | 612 kgf (6 000 N) |
| Magnet base dimensions | 243mm × 218 mm × 96 mm |
| Min. workpiece thickness | 5 mm |
| Tool holder | 19 mm (3/4'') Weldon |
