Promotech - Welding positioner PRO-WP 150, voltage 200-240V / 50-60Hz, power 0.25 kW, speed range min/max 0.12 - 2.4 rpm
Promotech - Welding Positioner PRO-WP 150
Weld positioners make it easy to turn round or tubular components, provide better access to the weld
better accessibility of the weld seam, help to produce high quality welds and increase
increase the deposition rate. Frequency inverters provide infinitely variable speed adjustment
and stabilisation of the speed at the set value. They reduce the time and
Time and effort for the welders, who can concentrate on their work without having to constantly move around in their
Work area to find the best position. The compact design takes up little space
Space and the inclination of up to 90 degrees improves the ergonomics of the workplace. The choice
of different attachments makes it possible to create an advanced modular welding station and to
and customise it according to the welding or cutting applications required to maximise production efficiency
maximise.
Advantages:
▪ Left or right rotation
▪ Stepless speed adjustment
▪ Speed stabilisation over the entire speed range from 0.12 rpm to 2.4 rpm
▪ Start/stop (both controller and foot pedal)
▪ Arc ignition
▪ Remote control
▪ Foot pedal for hands-free operation
▪ Robust construction
▪ Many additional accessories allow the construction of a modular welding station which is
suitable for various welding and cutting applications
| Technical datapRO-WP 150 | |
|---|---|
| Voltage | 1~ 220-240 V, 50-60 Hz 1~ 100-120 V, 50-60 Hz |
| Power | 0.25 kW |
| Speed range min/max | 0.12 - 2.4 rpm |
| Maximum load capacity | 150 kg |
| Offset of centre of mass from table at an inclination of 90 |
up to 100 mm |
| Diameter of the face plate | 450 mm |
| Hollow shaft inner diameter | 28 mm |
| Tilting range with infinitely variable angle adjustment | 0-90° |
| Tilt | manual |
| Max. Welding current transmission | 400 A |
| Weight | 115 kg |
