Pin - burnished Length 70 mm, with 3 pins to form a simple 90° angle, to stake out angles and clamps.
Fig. may deviate
Description
Product description
The locating pin is used, for example, to adjust angles that are only fixed with one clamping bolt in order to replace a second clamping bolt at low cost. Furthermore, different angles can be formed, e.g. 90° or 45°.
The picture shows an example of an application using templates provided by the customer.
This bolt is NOT permitted for connecting tables and U-shaped angles!
| Length (a) | 70 mm |
| Weight (a) | 0.4 kg |
